Specification
Indicate LED
Power x 1
USB host interface
Type B USB connector
USB output Ports
Type A USB 2.0 connector x 2
USB power on/off switch
USB interface chip set
USB 2.0 Compliant HUB controller
HS(480 Mbps), FS(12 Mbps), LS(1.5 Mbps) support
Internal reference clock
sCLK-EX12 board
External master clock input : Optional
Input frequency : 10MHz
Isolated clock input
50Ω BNC connector x 1
Power regulation circuit
Custom designed ultra low noise regulator circuit x 5
Standard ultra low noise regulator circuit x 1
Active noise canceler circuit
External power input
Input voltage : 9Vdc(Optional 12Vdc or Optional 6.5Vdc ~ 8.5Vdc)
Input current : 2A max
5.5mm OD, 2.1mm ID adaptor jack
USB port output power
Output voltage : +5.0V(+0.5V, -0.25V)
Over current protection : 0.8A at 20°C
Recommend output current : 0.5A >
Operating environment
Operating temperature : +10 ~ +30℃
Storage temperature : 0 ~ +40℃
Operating & storage humidity : 10% ~ 90%
Dimension
106 x 48 x 227(mm)
Weight
1.5kg >
